SmartScript PC-ECG System USB | Basic

SmartScript PC-ECG System USB | Basic

Dr. Gerhard Schmidt

Regular price £2,839.28 GBP
Regular price Sale price £2,839.28 GBP
Sale Sold out

Product Description

TheexpandableSmartScript PC ECG system from Dr. Gerhard Schmidt can be easily expanded from a 12-lead resting ECG to an ergo-spirometry system with the help of the appropriate modules. The recorded patient and ECG data are archived in anSQL-capable client/server databaseandcan be accessed and subsequently editedfrom any workstation to which the ECG system is connected.

Details

  • 12-lead, PC-ECG for resting ECGs
  • Intuitive operation
  • Comprehensive storage options
  • Delivered as a set, incl. cable, electrodes and software
  • With GDT interface

Overview

  • SmartScript PC ECG system from Dr Gerhard Schmidt
  • Can be upgraded from a resting ECG to an ergo-spirometer
  • Archiving of patient and ECG data in SQL-compatible client/server database
  • Examinations can be viewed from any integrated workstation
  • Subsequent editing and transmission via GDT and HL7 interface possible
  • Variable channel selection of ECG
  • Recording duration resting ECG: 10 seconds
  • Options: Rhythm ECG, electronic measurement, automatic interpretation
  • Recorded data can be evaluated digitally or printed out as desired
  • CE-marked software can be freely combined with other products (e.g.: Smartholder24 or SmartScan24)
  • Particularly economical
  • Optionally available with USB cable or Bluetooth
  • Various complete packages available
  • Recording speed: 5, 10, 25, 50 mm/s
  • 12 leads simultaneously
  • Sensitivity: 5, 10, 20 mm/mV
  • Filter: 35 Hz, low-pass filter, anti-drift
  • Pacemaker-proof
  • Sampling rate: 600 Hz
  • Resolution: 12 bit
  • Input impedance: > 20 MOhm
  • Common mode rejection: > 105 dB
  • Classification: IIa
  • Power consumption: < 2 Watt (BSC: 0.5 Watt)
  • Dimensions (USB): 188 x 98 x 45 mm (L x W x H)
  • Dimensions (Bluetooth): 162 x 85 x 31 mm (L x W x H)
  • Weight: approx. 350 g
  • Power supply: via PC (USB); via battery (Bluetooth)
  • Processor > 2 GHz
  • Working memory > 512 MB
  • Hard disk > 40 GB
  • Monitor > 19
  • Operating system: Windows 7/8/8.1/10 (32 or 64 bit)
