Kern OBE 122 Transmitted Light Microscope
Kern OBE 122 Transmitted Light Microscope
KERN
Regular price
£712.00 GBP
Regular price
Sale price
£712.00 GBP
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Product Description
ThebinocularKern OBE 122 transmitted-light microscope with its ergonomic and robust design is ideal forschools, training, laboratories and medical practices. Thecontinuously dimmable 3W LEDensures excellent illumination of the specimen to be examined, while theheight-adjustable and thereby focusable 1.25 Abbe condenser with aperture diaphragmguaranteesoptimal light bundling. In addition, the OBE 122 is equipped with anintegrated butterfly tube, which enables an ideal viewing angle.
Details
- Binocular all-round transmitted light microscope
- Integrated butterfly tube
- Practical storage compartment at the back
- 3W LED continuously dimmable
- Accessories included
Overview
- Kern transmitted light microscope OBE 122
- Binocular all-round transmitted light microscope
- Robust and ergonomic design
- Continuously dimmable 3W LED for brilliant illumination
- Height-adjustable and focusable 1.25 Abbe condenser with aperture diaphragm
- Ensures optimal light concentration
- Integrated butterfly tube for ideal viewing angle
- Height-adjustable stage with coarse and fine adjustment on both sides
- Specimens moved with the help of the coaxial drive
- Practical storage compartment on the back
- Power supply also possible with power bank via USB connection
- Ideal for schools, training, labs and medical practices
- Delivery contents: microscope, protective dust cover, eye cups and instructions for use
- Translucent and thin, high-contrast, low-demanding preparations (e.g. plant tissue, stained cells/parasites)
- Training
- Haematology
- Sediments
- Medical practices
- Finite optics (DIN)
- Ocular magnifications: 10 x
- 4x revolving nosepiece
- Eyepiece: HWF 10 x Ø 18.0 mm
- Achromatic objectives: 4 x, 10 x, 40 x
- Dimensions: 360 x 150 x 320 mm (W x D x H)
- Input current: AC 100-240 V, 50-60 Hz, 0.3 A
- Output current: DC 5V, 1.0 A
